Relation and Function is an integral topic of algebra in the class 11 Maths syllabus. As an important mathematical concept, it is also included under various scholastic and competitive exams. Often students are perplexed regarding the two essential concepts of Relation and Function. For all those going through similar confusion, we have devised helpful notes in this blog which will help you understand relations and functions.
This Blog Includes:
Relation and Function Theory
In the relation and function theory, we always represent an ordered pair as (INPUT, OUTPUT). In this, the Relation shows the relationship between INPUT and OUTPUT. On the other hand, a function represents a relation which is derived through one OUTPUT for every single INPUT.
All the functions are relations, but not all the relations are functions.
Now that you are familiar with the theory of relations and functions, let’s focus on the definition, types and examples to understand them better.
What is a Function?
A function can be described as a relation which represents that there should be only one output for every input. In other words, functions can be understood as a unique relation which follows the rule i.e., each and every value of X should be related to only one value of Y, then it will be called as a function.
A function comprises of Domain and Range. A Domain is a collection of first values in the ordered pair i.e., it is the set of all the inputs of the X variable. Whereas Range refers to the collection of the second values in the ordered pair i.e., it is the output of all the Y variables.
Domain | Range |
-1 | -3 |
1 | 3 |
3 | 9 |
Example of Functions:
For instance, the Relation is {(-2,3), (4,5), (6,-5), (-2,3)}.
Then, the Domain would be {-2, 4,6 } and {-5,3,5}.
Note: If any number appears more than once, it will only be written once in the domain as well as range.
Types of Functions
Now that you are familiar with its main concept, mentioned below are some types of functions you must know about to understand relations and functions in a better way.
Injective Function or One to One Function: In a function f: P→Q is considered to be One to One function only if every element of P there is a distinct element of Q.
Many to One Function: A function in which two or more elements of set P are mapped to the same element of set Q.
Surjective Function or Onto Function: It refers to a function where for every element of set Q there is a pre-image in set P.
Bijective Function or One-One and Onto Function: In the function f, each element of P is matched with a discrete element of Q and there is a preimage of every element of Q in P.
What are Relations?
Once you are familiar with functions, then it will be easier to grasp the concept of relations. In simple terms, relations can be simply understood as a subset of the Cartesian product or a bunch of points in an ordered pair.
For example: {(-2,1), (4,3), (7,-3)}
Representation of Relations
Apart from the common set notation, there are many other ways of representing a relation. Popular ways to do so are using tables, mapping diagram or plotting it on the XY axis.
Must Read: Pathways for Arts with Maths Students
Types of Relations
Similar to the types of functions, there are various relations through which we can learn about their different properties and these are:
- Universal Relations
- Empty Relations
- Inverse Relations
- Reflexive Relations
- Identity Relations
- Transitive Relations
- Symmetric Relations
Recommended Read: Career after BSc Maths
Class 11 NCERT Book
Click Here to download the NCERT book for class 11!
Relations and Functions: PDF
Solved Examples
Example 1: Identify the range and domain the relation below: {(-2, 3), {4, 5), (6, -5), (-2,3)}
Solution: Since the x values are the domain, the answer is, therefore,
⟹ {-2, 4, 6}
The range is {-5, 3, 5}.
Example 2: Check whether the following relation is a function: B = {(1, 5), (1, 5), (3, -8), (3, -8), (3, -8)}
Solution: B = {(1, 5), (1, 5), (3, -8), (3, -8), (3, -8)}
Though a relation is not classified as a function if there is a repetition of x – values, this problem is a bit tricky because x values are repeated with their corresponding y-values.
Example 3: Determine the domain and range of the following function: Z = {(1, 120), (2, 100), (3, 150), (4, 130)}.
Solution: Domain of z = {1, 2, 3, 4 and the range is {120, 100, 150, 130}
Example 4: Check if the following ordered pairs are functions:
- W= {(1, 2), (2, 3), (3, 4), (4, 5)
- Y = {(1, 6), (2, 5), (1, 9), (4, 3)}
Solution:
- All the first values in W = {(1, 2), (2, 3), (3, 4), (4, 5)} are not repeated, therefore, this is a function.
- Y = {(1, 6), (2, 5), (1, 9), (4, 3)} is not a function because the first value 1 has been repeated twice.
Example 5: Determine whether the following ordered pairs of numbers are a function. R = (1,1); (2,2); (3,1); (4,2); (5,1); (6,7)
Solution: There is no repetition of x values in the given set of ordered pairs of numbers.
Therefore, R = (1,1); (2,2); (3,1); (4,2); (5,1); (6,7) is a function.
Relations and Functions Practice Questions
1. Check whether the following relation is a function:
a. A = {(-3, -1), (2, 0), (5, 1), (3, -8), (6, -1)}
b. B = {(1, 4), (3, 5), (1, -5), (3, -5), (1, 5)}
c. C = {(5, 0), (0, 5), (8, -8), (-8, 8), (0, 0)}
d. D = {(12, 15), (11, 31), (18, 8), (15, 12), (3, 12)}
2. The Cartesian product B x B has 9 elements among which are found (–1, 0) and (0,1). Find the set B and the remaining elements of B x B.
3. Redefine the function: f(x) = |x – 1| – |x + 4|. Write its domain also.
4. Find the domain and range of the real function f(x) = x/1+x2.
5. If A = {a, b, c, d} & B = {e, f, g}. Is R = {(a, e) (a, f) (a, g) (b, e) (b, f) (b, g) (c, e) (c, f) (d, g)} a function from A to B.Give reasons to support your answer.
6. Let D be the domain of real valued function f defined by then, write D.
7. Let A = {a, b, c} and the relation R be defined on A as follows:
R = {(a, a), (b, c), (a, b)}.
Then, write the minimum number of ordered pairs to be added in R to make R reflexive and transitive.
8. If A = {a, b, c, d} and the function f = {(a, b), (b, d), (c, a), (d, c)}, write f – 1
9. be defined by
respectively. Then find g o f.
10. Is g = {(1, 1), (2, 3, (3, 5), (4, 7)} a function? If g is described by g(x) = αx + β, then what value should be assigned to α and β?
11. Determine the range and domains of the relation R defined by R = {(x – 1), (x + 2) : x ∈ (2, 3, 4, 5)}
12.Let A = {3, 4, 5} and B = {6, 8, 9, 10, 12}. Let R be the relation ‘is a factor of’ from A to B. Find R.
